SEMI-AUTOMATIC TOP LABELLING MACHINE-CE-803/TLM (Copy)

Looking for Enquiry? Ask for a quotation now and let us serve you!

Features

It is suitable for labeling on the upper plane, curved surface and concave surface of products. The precision of labeling is to ±0.5 mm. It is mainly used for labeling of electronic component and digital products, such as toys, SD cards, mobile phone batteries, FPC, mobile phone chargers, etc. High-precision labeling, show the excellent quality of products, improve competitiveness.



APPLICATION:

  1. Applicable labels: Sticker labels, Sticker films, electronic monitoring codes, bar codes, etc.
  2. Applicable products: products requiring labeling on flat, curved, circular, concave, convex or other surfaces.
  3. Application: widely used in cosmetics, food, toys, daily chemicals, electronics, medicine and other industries.
  4. examples: Shampoo flat bottle labeling, packaging box labeling, cap, plastic shell labeling, etc.



OPERATION PROCESS:

Put the product on machine — Affix the label (Automatic device implementation) — Take out the labeled product.





TECHNICAL PARAMETER:

Labeling accuracy± 0.5mm (Not include product and label errors)
Labeling speed15~30pcs/min (influenced by the size of the product and label)



Suit product sizeL:20~120mm W:20~180mm H:0.2~75mm



Suit label sizeL: 20mm-300mm   W:20-130mm
Machine sizeabout 880mm*560mm*880mm (length*width*height)



Voltage220V/50HZ
Machine weightAbout 60KG
The label inner diameterφ76mm
The label outer diameterφ300mm
Air pressure0.4~0.6Mpa
