Automatic Cartoning Machine is the newest model which is our company further improved on the basis of advanced technologies at home and abroad. It is the high-tech product whick integrates electricity, gas, light. The product is suitable for cartooning the pharmaceutical products, foods and cosmetic, poker, electronic and daily products and so on. The machine can finish automatically all hobs such as automatic side lining, carton opening, euro-hole folding, the stuff cartooned, carton sealing and so on. It can be used alone, or be linked with the other device, to be a production line.

Encasing speed25-35 boxes/min
BoxQuanlity requirementGray cardboard: 300-350g/m3

White cardboard: 250-350g/m3

Corrugated paper: customized

Dimension range (LxWxH)245 x 130 x 80mm (adjustable)
Compressed airWorking pressure0.5-0.8mpa
Air consumption20m3/h
Power supply240v/220v/380v 50Hz
Machine noise<70dm
Motor power1.5kw
Dimension4146 x 1306 x 1884mm (LxWxH)
Machine frameStainless steel, carbon steel and aluminum
Speed25-35 box/min
RemarkPLC micro-computer control

Aluminum alarm when box lack
